GembaRed UnderClocked Red & NIR Body-Light LED Panel

  • Sale
  • Regular price $1,590.00
Shipping calculated at checkout.

The GembaRed UnderClocked is the first ultra-low EMF and perfectly silent large body-light panel on the market!

Use this panel if you are serious about low-EMF, low-flicker, no noise, and effective intensity red and near-infrared light therapy.


    • Five wavelengths 630nm, 660nm, 810nm, 830nm, and 850nm.
      • Ultra Low EMF even at 0 inches!
      • True "cold" light therapy at proper intensities for PBM.
        • Effective intensity delivered with 60 degree lenses!
        • Eye comfort with lightly frosted lenses.
          • Ultra low-flicker DC powered LED Panel.
            • Sturdy metal enclosure and smooth features.
            • No Fans for a silent and comfortable experience!
            • External AC/DC adapter keeps EMF far away from the user!
            • Thin profile and floor stand included!
            • Simple, single switch control.
            • Patent-Pending Design!

                The GembaRed UnderClocked removed the fans and made the DC power adapter external to the panel. That is what makes it no noise and low EMF.

                Most other panels on the market tell you to be at least 6 inches away for EMF safety, that doesn't sound low-EMF to us. This panel is actually ultra-low EMF even at 0 inches away.

                Our innovative floor stand kit is included, as well as the standard door hanging accessories. The UnderClocked can be mounted on a TV Stand from our DIY Stand Guide. (vertical mounting only, upright)

                This large, sturdy panel is the perfect size for covering most of the torso. Full body red light therapy is best appreciated as a systemic therapy that delivers enough Joules over the body at low intensity at adequate exposure times. For direct deep penetrating therapy then a smaller skin-contact device is recommended instead.

                Built to last: The UnderClocked panel uses a simple switch with no fancy LCD screens or digital components that could cause a modern device to fail early. It has no fans that could also fail in traditional products. It uses the highest-industry standard MeanWell brand DC power external adapter with a metal enclosure on the adapter.


                Consumed Wattage: 140W

                LEDs: 252 LEDs


                25% - Red 630nm

                25% - Deep Red 660nm

                14% - Near-Infrared 810nm*

                22% - Near-Infrared 830nm*

                14% - Near-Infrared 850nm*

                *near-infrared bulbs are invisible to the eye and do not emit visible light, they look like they don't do anything!*

                3rd Party Verified Peaks:

                636nm, 664nm, 814nm, 837nm, 859nm

                Intensity Output:

                Distance from Panel         Power Density

                0 Inch                                 122* mW/cm²

                3 Inch                                 25  mW/cm²

                6 Inch                                 23  mW/cm²

                12 Inch                               18  mW/cm²

                18 Inch                               14  mW/cm²

                24 Inch                               11 mW/cm²

                36 Inch                                8 mW/cm²

                *Peak intensity directly over the LEDs

                11,000 Lux at 12 inches away

                Total Optical Watts Output: 48.75 W

                Total Joules Per Minute: 2,925 Joules

                Treatment Area:  46 inch X 10 inch

                Lens Angle: 60 degrees

                Weight: 25 lbs

                Panel Dimensions: 46 inch X 9.25 inch X 1 inch

                Lifetime: typical 50,000 hours

                Conformance: FCC, RoHS

                Warranty: 2 Year Limited Warranty

                Whats included?

                - GembaRed Beacon 2.0 LED Panel

                - External Power Adapter and Power Cord - US style plug only

                - Door Hanging Kit

                - Floor stand (kickstand style) kit

                - Timer

                - Bamboo Ruler

                Example Usage:

                0-3 inches from the skin for 1-3 minutes per session. (deep penetration)

                6-18 inches away from skin for 10 minutes each side. (systemic benefits)

                24-36 inches away for face for 10 minutes (skin care & eye health)

                Use up to 2 times per day on the desired area or as little as 3 times per week for adequate benefits.

                IsoPlot at 12 inches Away:

                Average Intensity at 12 inches: 14 mW/cm²

                Additional Details:

                Power Adapter: AC 85-264V (works internationally)

                Frequency: 50/60 HZ

                LEDs: 252 LEDs, 3 Watt Rated Bulbs

                Enclosure: Metal enclosure with white coating

                Flicker Measurements:

                Flicker Percentage: 0.4 %

                Flicker Frequency: 124 Hz

                EMF Measurements (front of the panel):

                0 inches:

                2 V/m Electric Field (less than ambient due to grounding)

                0.66 milliGauss Magnetic Field (near-ambient)


                Shipping within the USA is FREE! Please allow 3-6 business days processing time to ship, and an additional 2-10 business days for delivery depending on the location.

                We do not ship internationally at this time.

                Not Sure Which GembaRed panel is right for you? Check our Product Guide by clicking here.

                Made In China

                ** Disclaimer: This panel is designed for general wellness and information provided is for educational use only. As with starting any new general wellness activity such as fitness, diet, or supplementation; we advise you to meet with your wellness practitioner to ensure there are no contraindications with your current condition. Use of GembaRed LLC products or information does not constitute medical advice or treatment, and should not be used as a substitute for medical advice or treatment. Consult your doctor or biohacking coach for recommendations on how to effectively apply red light to your wellness routine.
